Key Features:
1 / 2.7 ” sensor 1080P 2.0mp HD resolution
50 faces capture multiple people at the same time, 20 * 20 lower minimum capture, the capture rate is as high as 99%.
Realize a variety of behavior detection such as area intrusion, hover detection, fast movement, cross-border detection, face detection
Supports various alarms such as motion detection, occlusion detection, sound detection, alarm input, alarm output, etc.
Smart light sensitive day and night switching is more accurate, and the face metering image is brighter and more balanced
Support 2D / 3D noise reduction
Support 100dB optical wide dynamic
Advanced H.265 encoding algorithm for higher encoding compression efficiency
Support Onvif international standard protocol, can access third-party backend / platform
Web-side support and SDK development
|
|
Model
|
SY-F22AI
|
|
System structure
|
8GB EMMC,8Gb*1 DDR4
|
|
Sensor
|
1/2.7", 2.0 megapixel, progressive scan, CMOS
|
|
Video processing
|
H.265, H.264,MJPEG Video Compression
Support adjustable stream 128kb~ 16384kb
Frame rate 1~30fps
|
|
Image Output
|
Main Stream:1080P
Sub Stream:640X360,D1,2CIF,CIF
|
|
Shutter
|
Auto/Manual, 1~1/100000 s
|
|
Day/Night
|
Support IR Cut,Day/Night
|
|
WDR
|
100dB
|
|
Lens
|
3.6/6/8/12mm for option
|
|
Digital noise reduction
|
2D/3D DNR
|
|
Audio Port
|
1ch I/O
|
|
Alarm Port
|
2ch input,1ch output
|
|
RS485 Port
|
Support
|
|
Network
|
10/100M Base-TX Ethernet
Support IPv4,TCP,UDP,RTP,RTSP,DNS,HTTP,ICMP,ARP,HTTPS,SSL,DHCP,PPPoE,
DDNS,NTP,FTP,UPnP,802.1X etc Protocols
|
|
Reset Button
|
Support
|
|
SD Card
|
Support
|
|
Intelligent
|
Support motion detection, cross-border detection, entering area, leaving area, area invasion, hovering area, fast movement, people gathering, item removal, item leftover, etc
Supports face detection, face recognition, etc.
|
|
Function
|
Support motion detection, occlusion detection, OSD configuration, image configuration, intelligent monitoring etc.
|
|
Face capture speed
|
Millisecond recognition
|
|
ONVIF
|
Support
|
|
Working Environment
|
-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing)
|
|
|
|
