Description:
This product is applicable to the lightning and electric surge protection of the video signal circuit, control wiring and power circuit of monitor camera. It can combine the above mentioned lightning protection function into one. Its housing adopts integrated aluminum-alloy structure with small volume and ultra low residual pressure output. Design of this product considers fully that the electrode capacitance and distributed capacitance would lessen data signaling with small insertion loss, which can satisfy the requirement of video signal transmission, and can response to the transient overvoltage quickly.
Key features:
1. 100MHz cctv (2-in-1) video & power supply surge protector;
2. Outside Install Type;
3. 220VAC Control Line, RJ45 port;
4. Multi-level protection circuit, residual depression;
5. Four wire protection: 1.2.3.6 line;
6. High transmission band, fast response, low insertion loss;
7. Exquisite appearance, small size, easy to stall;
8. Ground through a special process to avoid signal interference.
|
